Removal & Installation: Notes
WARNING:
When replacing fuel line parts, be sure to observe the following:
- Put a "CAUTION: INFLAMMABLE" sign in workshop.
- Do not smoke while servicing fuel system. Keep open flames and sparks away from work area.
- Be sure to furnish the workshop with a CO2 fire extinguisher.
CAUTION:
- Before removing fuel line parts, carry out the following procedures:
- Put drained fuel in an explosion-proof container and put lid on securely.
- Release fuel pressure from fuel line. Refer to FUEL PRESSURE RELEASE .
- Disconnect battery ground cable.
- Remove quick connectors with commercial service tool.
- Always replace O-ring with a new one.
- Do not kink or twist hoses and tubes when installed.
- Do not tighten hose clamps excessively to avoid damaging hoses.
- Perform an inspection and installation of EVAP system parts as necessary. Refer to EMISSION SYSTEMS .
- For inspection and installation of ORVR system parts, refer to ON-BOARD REFUELING VAPOR RECOVERY SYSTEM .
- After installation, run engine and check for fuel leaks at connections.
- Use only a genuine NISSAN fuel filler cap as a replacement. If an incorrect fuel filler cap is used, the MIL may come on.
