Method A

  1. Slide the harness protector of ignition coil No. 1 to clear the wires.
  2. Attach timing light to the ignition coil No. 1 wires as shown in the figure.
  3. Check ignition timing.
    Fig 1: Checking Ignition Timing
    G00772616Courtesy of NISSAN MOTOR CO., U.S.A.
