Rear Refrigeration System

WARNING: This page is about a different car, the 2005 Nissan Quest. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Rear Refrigeration System Replacement Components - With Torque Specifications

Courtesy of NISSAN MOTOR CO., U.S.A.
