Daytime Light System: Schematic

WARNING: This page is about a different car, the 2006 Infiniti G35. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Daytime Light System Schematic

Courtesy of NISSAN MOTOR CO., U.S.A.
