Hood Ledge: LH

WARNING: This page is about a different car, the 2006 Nissan Xterra. However, it is still accessible from the selected car via links, so may be relevant.

Work after radiator core support has been removed.

Fig 1: Locating Hood ledge LH

Courtesy of NISSAN MOTOR CO., U.S.A.
