Section 306 (Front Suspension): Description

WARNING: This page is about a different car, the 2003 Infiniti G35. However, it is still accessible from the selected car via links, so may be relevant.

G35 uses a MacPherson strut-type front suspension system. See Fig 1 or Fig 2 . Strut assembly consists of a shock absorber and coil spring. Upper end of strut is bolted to body of vehicle. Lower end of strut is bolted to transverse link. Steering knuckle is attached to transverse link and upper link by a ball joint.

Fig 1: Exploded View Of Front Suspension Components (Coupe)

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 2: Exploded View Of Front Suspension Components (Sedan)

Courtesy of NISSAN MOTOR CO., U.S.A.
