Cooling Fan Motor

  1. Disconnect cooling fan motor harness connector.
  2. Supply cooling fan motor terminals with battery voltage and check operation.

    Cooling fan motor should operate.

    If NG, replace cooling fan motor.

    Fig 1: Disconnecting Cooling Fan Motor Harness Connector
    G02443933Courtesy of NISSAN MOTOR CO., U.S.A.
