Notes
Disassembly and Assembly: Notes
Fig 1: Installing Radiator (QG18DE Engine, With Torque Specifications)
Courtesy of NISSAN MOTOR CO., U.S.A.
Courtesy of NISSAN MOTOR CO., U.S.A.
