Body (Alignment)
›
Alignment
›
Engine Compartment
›
Measurement Points
Measurement Points
Fig 1: Identifying Engine Compartment Measurement Points
Courtesy of NISSAN MOTOR CO., U.S.A.
Courtesy of NISSAN MOTOR CO., U.S.A.
