FixVault
Home
›
Nissan-Datsun
›
2012
›
Leaf SL
›
Repair and Diagnosis
›
Body & Frame
›
Mirrors
›
Removal And Installation
›
Inside Mirror
›
Exploded View
Exploded View
Fig 1: Exploded View Of Inside Mirror With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Courtesy of AMERICAN HONDA MOTOR CO., INC.
