Disassembly and Assembly: Assembly

Note the following, and assemble in the reverse order of disassembly.

• Install oil pump inner rotor with the groove faced to oil pump cover side.

Fig 1: Identifying Punched Marks On Oil Pump Inner Rotor

Courtesy of NISSAN NORTH AMERICA, INC.
