System Description
›
4WD System
›
Cross-Sectional View
Cross-Sectional View
Fig 1: ATP Warning Lamp (A/T Models) Cross-Sectional View
Courtesy of NISSAN NORTH AMERICA, INC.
Courtesy of NISSAN NORTH AMERICA, INC.
