Removal and Installation: Removal

Remove instrument pad LH. Refer to "EXPLODED VIEW ".
Release the pawl on each side of NATS antenna amp (1) using a suitable tool and remove from the instrument pad LH.

Fig 1: Removing Instrument Pad (LH) Using Tool
Courtesy of NISSAN NORTH AMERICA, INC.
Release the pawl on each side using a suitable tool and remove the push-button ignition switch from the NATS antenna amp.
