Special Service Tools

The actual shape of the tools may differ from those illustrated here.

Tool number (TechMate No.) Tool name		Description
-- (J-28431)	Courtesy of NISSAN NORTH AMERICA, INC.	Fluorescent Oil Dye
-- (J-43926) A/C Leak Detection Kit Kit includes: (J-42220) UV lamp and UV safety goggles (J-41459) Refrigerant dye injector (J-41447) Fluorescent leak detection dye (box of 24, 1/4 ounce bottles) (J-43872) Refrigerant dye cleaner	Courtesy of NISSAN NORTH AMERICA, INC.	Power supply: DC 12V (battery terminal)
(--) (J-52584) CVT stand pipe adapter kit	Courtesy of NISSAN NORTH AMERICA, INC.	CVT fluid changing and adjustment
KV311039S0 (--) Charging pipe set KV31103920* (--) O-ring	Courtesy of NISSAN NORTH AMERICA, INC.	CVT fluid changing and adjustment
(--) (J-52584) CVT stand pipe adapter kit	Courtesy of NISSAN NORTH AMERICA, INC.	CVT fluid changing and adjustment
KV38107900 (J-52469-1) Differential side oil seal protector	Courtesy of NISSAN NORTH AMERICA, INC.	Installing drive shaft A: 32 mm (1.26 in) dia B: Minimum 23 mm (0.91 in)
J-52306 CVT Transmission Range Switch (PNP) A. Pin B. Guage	Courtesy of NISSAN NORTH AMERICA, INC.	Replacing transmission range switch
(J-02611) CVT charge pipe cap release tool	Courtesy of NISSAN NORTH AMERICA, INC.	Removing CVT charge pipe cap

*: The O-ring as a unit part is set as a SST.
