Component Parts Location
|
Type A* meter |
Type B* meter |
Shifter assembly |
|||
|
Pedal periphery area |
Transaxle assembly |
||||
|
IPDM E/R |
BCM |
ABS actuator and electric unit (control unit) |
|||
|
ECM |
Combination meter |
Malfunction indicator lamp |
|||
|
Shift position indicator |
Ds mode switch |
Brake pedal position switch |
|||
|
Stop lamp switch |
Accelerator pedal position sensor |
Transmission range switch |
|||
|
Input speed sensor |
CVT unit connector |
Control valve |
|||
|
Primary speed sensor |
Output speed sensor |
||||
*: For details of TYPE, refer to Information .
NOTE:
- The following components are included in control valve assembly.
- CVT fluid temperature sensor
- Primary pressure sensor
- Secondary pressure sensor
- Line pressure solenoid valve
- Primary pressure solenoid valve
- Secondary pressure solenoid valve
- Torque converter clutch solenoid valve
- Select solenoid valve
