System Description
SYSTEM DIAGRAM
NOTE:
The following parts apply to idle start/stop system.
- Crankshaft position sensor 2
- DC/DC converter
- Engine restart bypass relay
- Engine restart bypass control relay
- Start/Stop indicator lamp
- Start/Stop OFF switch
SYSTEM DESCRIPTION
ECM controls the engine by various functions.
| Function | Reference |
|---|---|
| Direct injection gasoline system | System Description |
| Electric ignition system | System Description |
| Fuel pressure control | System Description |
| Fuel pump control module (FPCM) | System Description |
| Intake valve timing control | System Description |
| Exhaust valve timing control | System Description |
| Air conditioning cut system | System Description |
| Engine oil pressure control system | System Description |
| Engine protection control at low engine oil pressure | System Description |
| Cooling fan control | System Description |
| Evaporative emission system | System Description |
| Throttle control | System Description |
| Intake manifold runner control | System Description |
| Automatic speed control device (ASCD) | System Description |
| Fuel filler cap warning system | System Description |
| CAN communication | System Description |
