Window Regulator Motor: Installation

1. Install motor to regulator using 3/16" rivets. See Fig 1 .
2. Install screw and nut locking sector gear in a fixed position.
3. Install the regulator. See WINDOW REGULATOR  .

Fig 1: Identifying Window Motor On Window Regulator

Courtesy of GENERAL MOTORS CORP.
