Speed Sensor Test
- Connect the ground wire from the test light to terminal No. 6 and connect the positive probe from the test light to terminal No. 10. Drive the vehicle slowly.
- Test light should flash on and off as the vehicle moves. If not, replace the sensor located inside the speedometer housing. If the above tests fail to locate the problem, replace the electronics package.
