Installation Procedure

WARNING: This page is about a different car, the 2002 Pontiac Aztek and 2002 Buick Rendezvous. However, it is still accessible from the selected car via links, so may be relevant.

Press the upper end of the assist rods on to the ball joint on the hood.

Fig 1: Pressing Upper End Of Assist Rod On Ball Joint On Hood
Courtesy of GENERAL MOTORS CORP.
Press the lower end of the assist rods on to the ball joint on the lower hood hinge
Remove the support from the hood.
Close the hood.

Fig 2: Pressing Lower End Of Assist Rod On Ball Joint On Lower Hood Hinge
Courtesy of GENERAL MOTORS CORP.
