Test A: Scan Tool Does Not Power Up: Testing

  1. Check for battery voltage at DLC terminal No. 16 (Orange wire). See Figure . If battery voltage exists, go to next step. If battery voltage does not exist, repair open or short to ground in Orange wire between DLC terminal No. 16 and left Instrument Panel (IP) junction block fuse IPC/HVAC BATT (10-amp) output cavity. See Figure . After repairs are made, go to step  5 .
  2. Check for open in Black wire between ground and DLC terminal No. 4. Ground point is located at left upper corner of dash, under instrument panel. If no problem is found, go to next step. If problem is found, repair circuit as necessary and go to step  5 .
  3. Check for poor or loose connections between scan tool and DLC terminals No. 4 and 16. If no problems are found, go to next step. If problem is found, repair as necessary and go to step  5 .
  4. Scan tool may be malfunctioning. Check scan tool manual for diagnostic procedures. After repairs are made, go to next step.
  5. Perform diagnostic system check. See BODY CONTROL SYSTEM DIAGNOSTIC SYSTEM CHECK  . If referred from another article, return to that article and perform diagnostic system check.
