Removal Procedure

WARNING: This page is about a different car, the 2002 Oldsmobile Aurora. However, it is still accessible from the selected car via links, so may be relevant.
  1. Open the rear compartment lid.
  2. Remove the appropriate rear compartment side trim panel. Refer to COMPARTMENT TRIM PANEL REPLACEMENT--REAR .
  3. Remove the tail lamp housing assembly. Refer to Tail Lamp Replacement .
  4. Remove the tail lamp socket from the tail lamp housing assembly (3) by turning counter clockwise 1/4 turn.
  5. Remove the tail lamp bulb from the socket.
    Fig 1: Removing Tail Lamp Bulb
    G01802991Courtesy of GENERAL MOTORS CORP.
