Torque Specifications
WARNING: This page is about a different car, the 2002 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.
TORQUE SPECIFICATIONS
| Application |
Ft. Lbs. (N.m) |
| Camshaft Sprocket Bolt |
103 (140) |
| Crankshaft Balancer Bolt |
76 (103) |
| Cylinder Head Bolt |
| First Pass |
44 (60) |
| Final Pass |
Tighten an Additional 95° |
| Drive Belt Tensioner Bolt |
37 (50) |
| Engine Coolant Temperature (ECT) Sensor |
17 (23) |
| Engine Mount-to-Engine Mount Bracket Bolt |
43 (58) |
| Engine Mount to Body Nut |
32 (43) |
| Engine Mount to Engine Mount Adapter Plate Nut |
35 (47) |
| Engine Oil Drain Plug |
18 (25) |
| Flywheel Bolt |
61 (83) |
| Front Cover Bolt (Large) |
35 (47) |
| Frojnt Cover Bolt (Small) |
15 (21) |
| Oil Filter Adapter |
21 (29) |
| Oil Level Indicator Tube Bolt |
18 (25) |
| Oil Pan Bolt |
18 (25) |
| Oil Pan Bolt (Side) |
37 (50) |
| Oil Pump Nut |
30 (41) |
| Oil Pump Drive Bolt |
27 (36) |
| Timing Chain Tensioner Dampener Bolt |
15 (21) |
| Upper Intake Manifold Bolt |
18 (25) |
| Valve Lifter Guide Bolt |
89 (10) |
| Water Outlet Bolt |
18 (25) |
| INCH Lbs. (N.m) |
| Fuel Pipe Clip Bolt |
71 (8) |
| Lower Intake Manifold Bolt |
115 (13) |
| Valve Rocker Arm Bolt |
| First Pass |
124 (14) |
| Final Pass |
Tighten an Additional 30° |
| Valve Rocker Arm Cover Bolt |
89 (10) |
Courtesy of GENERAL MOTORS CORP.
Courtesy of GENERAL MOTORS CORP.
