Installation Procedure

  1. Install the speaker to the door trim panel assembly.

    Tighten

    Tighten the speaker screws to 3.2 N.m 28 lb in).

  2. Connect the wire harness to the speaker.
  3. Install the trim panel assembly to the front door. Refer to TRIM PANEL REPLACEMENT -- SIDE FRONT DOOR (AZTEK) or TRIM PANEL REPLACEMENT -- SIDE FRONT DOOR (RENDEZVOUS) .
    Fig 1: Installing Speaker To Door Trim Panel Assembly
    G01517485Courtesy of GENERAL MOTORS CORP.
