Installation Procedure

WARNING: This page is about a different car, the 2003 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.

Install the bulb to the socket.
Install the socket to the lamp assembly.

Fig 1: Installing Bulb To Socket
Courtesy of GENERAL MOTORS CORP.
Position the brake caliper cooling duct to the front fascia and press the duct toward the fascia to secure.
Install the front fascia lower closeout panel. Refer to CLOSE OUT PANEL - FRONT BUMPER FASCIA LOWER in Bumpers.
Lower the vehicle.

Fig 2: Positioning Brake Caliper Cooling Duct To Front Fascia
Courtesy of GENERAL MOTORS CORP.
