Front Side Door Window Switch Replacement

Fig 1: Identifying Front Side Door Window Switch

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Instrument Panel Center Trim Bezel Refer to Instrument Panel Accessory Bezel Replacement
2	Front Power Window Switch Screw (Qty: 4) NOTE: Refer to Fastener Notice . Tighten:  2.5 N.m (22 lb in)
3	Front Power Window Switch Assembly Tip:  Disconnect electrical connectors.
