Humidity Sensor

WARNING: This page is about a different car, the 2018 Land Rover Discovery and 2017 Land Rover Discovery. However, it is still accessible from the selected car via links, so may be relevant.

The humidity sensor is installed in a bracket attached to the inside of the windshield, to the right of the interior mirror. The sensor is concealed under a cover, which clips onto the bracket. The sensor comprises three individual elements:

A capacitive humidity sensor
A Negative Temperature Coefficient (NTC) thermistor air temperature sensor
An infrared windshield glass temperature sensor.
NOTE: This component is not fitted to the 2 Zone manual system.
