DTC P0112: Intake Air Temperature Sensor Circuit (Short to Ground)
›
Notes
DTC P0112: Intake Air Temperature Sensor Circuit (Short to Ground): Notes
Fig 1: Identifying Intake Air Temperature Sensor Circuit Diagram - Short To Ground
Courtesy of SAAB-SCANIA OF AMERICA, INC.
Courtesy of SAAB-SCANIA OF AMERICA, INC.
