Component Location
›
Grounding Point G25
›
Notes
Grounding Point G25: Notes
Fig 1: Locating Battery Grounding Point (G25)
Courtesy of SAAB-SCANIA OF AMERICA, INC.
Fig 2: Battery Grounding Connection Diagram (G25)
Courtesy of SAAB-SCANIA OF AMERICA, INC.
Location:
On the gearbox.
