System overview

Fig 1: Identifying Seat-Belt System Overview
G03562180Courtesy of SAAB-SCANIA OF AMERICA, INC.

Seat-belt system

  1. Seat belts with belt tensioners
  2. Rear seat belts
  3. Seat-belt warning
