Control module, PSG 16 (595)

Fig 1: Identifying PSG 16 Control Module
G03617850Courtesy of SAAB-SCANIA OF AMERICA, INC.
TECHNICAL DATA - PSG 16 CONTROL MODULE

No. of pins     56 on K switch and 56 on M switch
Power supply (+15 circuit)   pin no. 16(K)
P-bus + pin no. 29(K)
  - pin no. 17(K)
