2-4 Brake

Apply ATF to new D-ring, and install it to 2-4 brake piston.

Install 2-4 brake piston to 2 -4 brake piston retainer.

Fig 1: Applying ATF To New D-Ring

Courtesy of SAAB-SCANIA OF AMERICA, INC.

1. 2-4 brake piston
2. 2-4 brake piston retainer
