Side Retainer

Remove the O-ring.

Fig 1: Removing O-Ring

Courtesy of SAAB-SCANIA OF AMERICA, INC.

Remove the oil seal.

NOTE: Do not reuse the oil seal. Prepare a new oil seal.

Fig 2: Removing Oil Seal

Courtesy of SAAB-SCANIA OF AMERICA, INC.
