Generator 130A, 4-CYL Petrol

Fig 1: Identifying Generator 130A (4-Cyl Petrol)

Courtesy of SAAB-SCANIA OF AMERICA, INC.

GENERATOR SPECIFICATIONS 130A (4-CYL PETROL)

Type designation		Bosch NC 14V 65-130A
Rated voltage	V	14
Stator connection		Delta connection
Slip ring diameter: new min	mm mm	15.4 14.4
Max. permissible radial runout: belt pulley slip rings rotor	mm mm	0.2 0.02 0.087
Min. brush length, from brush holder opening	mm	7.5
Ratio crankshaft/generator belt pulleys		1:2.85
Test values
Resistance, rotor winding Resistance, stator between phases	Ohm Ohm	2.6 0.051
Generator RPM/rated current at: 1800 RPM 6000 RPM	A A	65 130
