Radiator Support Replacement

Fig 1: Identifying Radiator Support And Fastener

Courtesy of SAAB-SCANIA OF AMERICA, INC.

Callout	Component Name
Preliminary Procedure  Remove the front bumper fascia. Refer to FRONT BUMPER FASCIA REPLACEMENT Support the radiator.
1	Radiator Support Fastener (Qty: 4) Refer to FASTENER CAUTION . Procedure  Support the radiator. Tighten  25 Nm (18 lb ft)
2	Radiator Support (Qty: 2)
