Removal Procedure

NOTE: Do not remove the left bank idler sprocket.

Remove the primary timing chain. Refer to PRIMARY CAMSHAFT DRIVE CHAIN AND SPROCKETS REPLACEMENT .

Fig 1: Identifying Crankshaft Sprocket
Courtesy of SAAB-SCANIA OF AMERICA, INC.
Remove the crankshaft sprocket. Refer to CRANKSHAFT SPROCKET REMOVAL .
Remove the oil dipstick. Refer to OIL PUMP REMOVAL .
