Primary Timing Chain Guide Removal - Upper

  1. Remove the primary camshaft drive chain upper guide bolts.
    Fig 1: Identifying Primary Camshaft Drive Chain Upper Guides And Mounting Bolts
    G09438613Courtesy of SAAB-SCANIA OF AMERICA, INC.
  2. Remove the primary camshaft drive chain upper guides.
