L61 Engine Torque Specifications

Fig 1: Engine Torque Specifications (1 Of 5)

Courtesy of GENERAL MOTORS CORP.

Fig 2: Engine Torque Specifications (2 Of 5)

Courtesy of GENERAL MOTORS CORP.

Fig 3: Engine Torque Specifications (3 Of 5)

Courtesy of GENERAL MOTORS CORP.

Fig 4: Engine Torque Specifications (4 Of 5)

Courtesy of GENERAL MOTORS CORP.

Fig 5: Engine Torque Specifications (5 Of 5)

Courtesy of GENERAL MOTORS CORP.
