Ignition Module (Unit Repair): Installation

Install spark plugs.
Torque:

Spark Plug: 25 N.m (18 ft-lbs)
Install ignition module.

Fig 1: Installing Ignition Module
Courtesy of GENERAL MOTORS CORP.
Install ignition module bolts.
Torque:

Ignition Module Bolt: 8 N.m (71 in-lbs)
