Installation Procedure

Fig 1: Ignition Lock Bezel

GM866450

Courtesy of GENERAL MOTORS CORP.

Position steering column lower shroud to steering column.
Secure steering column upper and lower shrouds with shroud fasteners.
Tighten: Tighten Steering Column Shroud Fasteners 1.5 N.m (13 lbs in).
Install ignition bezel.
1. Align peg of bezel with the cut-out in lower shroud.
2. Snap into place.
