Automatic Transaxle - AF23-5
›
Specifications
›
Line Pressure
Line Pressure
Fig 1: Line Pressure - Transmission In Park (P)
Courtesy of GENERAL MOTORS CORP.
Fig 2: Line Pressure - Transmission In Reverse (R)
Courtesy of GENERAL MOTORS CORP.
Fig 3: Line Pressure - Transmission In Drive (D)
Courtesy of GENERAL MOTORS CORP.
Courtesy of GENERAL MOTORS CORP.
Courtesy of GENERAL MOTORS CORP.
Courtesy of GENERAL MOTORS CORP.
