Automatic Transaxle - AF23-5
›
Specifications
›
Transmission Fluid Temperature (TFT) Sensor Specifications
Transmission Fluid Temperature (TFT) Sensor Specifications
Fig 1: Transmission Fluid Temperature (TFT) Sensor Specifications
Courtesy of GENERAL MOTORS CORP.
Courtesy of GENERAL MOTORS CORP.
