Installation Procedure

    Fig 1: Removing & Installing Child Restraint Bracket
    GM896448Courtesy of GENERAL MOTORS CORP.
    NOTE: Refer to FASTENER NOTIC in Cautions and Notices.
  1. Install the child restraint fastener and the bracket to the vehicle.

    Tighten:  Tighten the bracket bolt to 20 N.m (15 lb ft).

    2. Fig 2: Removing & Installing Load Floor Panel
    GM896668Courtesy of GENERAL MOTORS CORP.
  2. Install the load floor panel.
