Headlamp Bulb Replacement
WARNING: This page is about a different car, the 2007 Pontiac G5 Pursuit, 2007 Pontiac G5, and 2007 Chevrolet Cobalt. However, it is still accessible from the selected car via links, so may be relevant.
Headlamp Bulb Replacement
| Callout | Component Name |
|---|---|
|
NOTE:
Refer to Fastener Notice
. Preliminary Procedure Remove either the LF or RF headlamp assembly. Refer to Tail Lamp Replacement (Chevy Coupe) or Tail Lamp Replacement (Chevy/Pontiac Sedan) or Tail Lamp Replacement (Chevy Export) . |
|
| 1 | Headlamp Bulb Locking Ring Tip: Turn the ring counter-clockwise and remove. |
| 2 |
CAUTION:
Refer to Halogen Bulb Caution
. Headlamp Bulb |
| 3 | DRL, Park and Turn Signal Lamp Socket |
| 4 | DRL, Park and Turn Signal Bulb Tip: Pull the bulb straight from the socket in order to remove. |
