Installation Procedure

    Fig 1: Identifying Torque Converter Cover Bolts
    GM289471Courtesy of GENERAL MOTORS CORP.
  1. Install the torque converter cover.
    2. NOTE: Refer to Fastener Notice .
  2. Install the torque converter cover bolts.

    Tighten:  Tighten the bolts to 10 N.m (89 lb in).

    3. Fig 2: Removing/Installing Transmission Brace (Front Wheel Drive & All Wheel Drive)
    GM1544756Courtesy of GENERAL MOTORS CORP.
  3. Install the transaxle brace (4). Refer to Automatic Transmission Brace Replacement (Front Wheel Drive)  or Automatic Transmission Brace Replacement (All Wheel Drive)  or Automatic Transmission Brace Replacement (Front Wheel Drive and All Wheel Drive) .
  4. Lower the vehicle.
