Rear Compartment Lid Switch Replacement

WARNING: This page is about a different car, the 2008 Pontiac G5 and 2008 Chevrolet Cobalt. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: View Of Rear Compartment Lid Switch

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
Preliminary Procedure: Remove the steering column opening filler. Refer to Steering Column Opening Filler Replacement .
1	Rear Compartment Lid Release Switch Assembly Tip: Disconnect the electrical connector. Push the 2 tabs in to release the switch.
