Transmission Revolution Sensor: Installation

INSTALL SPEED SENSOR (NC SENSOR)
1. Coat a new O-ring with ATF and install it to the sensor.
2. Install the sensor with the bolt.
  Torque: 8.8 N*m (90 kgf*cm, 78 in.*lbf)
3. Connect the sensor connector.
Fig 1: Installing Speed Sensor (NC Sensor)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSTALL SPEED SENSOR (NT SENSOR)
1. Coat a new O-ring with ATF and install it to the sensor.
2. Install the sensor with the bolt.
  Torque: 11 N*m (115 kgf*cm, 8 ft.*lbf)
3. Connect the sensor connector.
INSTALL AIR CLEANER ASSEMBLY
Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf)
INSTALL BATTERY CARRIER (See INSTALLATION )
INSTALL BATTERY (See INSTALLATION )

Fig 2: Installing Speed Sensor (NT Sensor)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
PERFORM INITIALIZATION
1. Perform initialization (see INITIALIZATION ).
  NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
