Code 22: Knock Sensor
Code 22: Knock Sensor
Fig 1: Schematic - Code 22, Knock Sensor
Fig 2: Flow Chart - Code 22, Knock Sensor
Fig 3: Code 22, Flow Chart Diagnostic Aids
Courtesy of SUBARU OF AMERICA, INC.
Courtesy of SUBARU OF AMERICA, INC.
