| Camshaft Sprocket Bolt |
55-61 (75-83) |
| Camshaft Support Bolt |
12 (16) |
| Connecting Rod Cap Nut |
32-34 (43-46) |
| Crankshaft Pulley Bolt |
69-76 (93-103) |
| Cylinder Block Bolt (Left-To-Right) |
17-20 (23-27) |
| Cylinder Block Service Hole Plug |
46-56 (62-76) |
| Cylinder Head Bolt |
| Step 1 |
21 (29) |
| Step 2 |
51 (69) |
| Step 3 |
Loosen 180° |
| Step 4 |
Loosen 180° |
| Step 5 |
27 (36) |
| Step 6 |
Tighten 80-90° |
| Step 7 |
Tighten 80-90° |
| Drive Plate Reinforcement Bolt |
51-55 (69-75) |
| Flywheel Bolt |
51-55 (69-75) |
| Timing Belt Idler Bolt |
26-32 (35-43) |
| Timing Belt Tension Adjuster Bolt |
17-20 (23-27) |
| Timing Belt Tensioner Bracket Bolt |
17-20 (23-27) |
| INCH Lbs. (N.m) |
| Oil Pan Bolt |
44 (5.0) |
| Oil Pump Bolt |
58 (6.4) |
| Rocker Cover Bolt |
44 (5.0) |
| Rocker Shaft Support Bolt |
| Long |
108 (12.2) |
| Short |
44 (5.0) |
| Thermostat-to-Water Pump Bolt |
52-61 (6-7) |
| Timing Belt Cover Bolt |
44 (5.0) |
| Water Pump Bolt |
89-124 (10.0-14.0) |
