Generator Specifications
WARNING: This page is about a different car, the 2004 Subaru Impreza and 2003 Subaru Impreza. However, it is still accessible from the selected car via links, so may be relevant.
BRUSH SPECIFICATIONS
| Application (1) | Specification | |||
|---|---|---|---|---|
| Brush Length | ||||
| Standard | .728" (18.5 mm) | |||
| Limit | .197" (5 mm) | |||
| Brush Spring Pressure | ||||
| New | 16.58-20.81 oz. (4.61-5.78 N) | |||
| Replace | 9.52 oz. (2.65 N) | |||
|
||||
ROTOR ASSEMBLY SPECIFICATIONS
| Application | Specifications | |
|---|---|---|
| Slip Ring Continuity Test | ||
| Specified Resistance | 1.8-2.2 Ohms | |
| Slip Ring Outer Diameter | ||
| Standard | .894" (22.7 mm) | |
| Limit | .87" (22.1 mm) | |
