DTC 41: Abnormal Abs Control Module
›
Diagnostic Procedures:
Diagnostic Procedures:
Fig 1: Abnormal ABS Control Module Wiring Diagram Diagnostic Procedure Chart
Courtesy of SUBARU OF AMERICA, INC.
Courtesy of SUBARU OF AMERICA, INC.
